Concrete Drilling Range(mm) | Rated Voltage(v) | Rated Frequency(Hz) |
Rated Input Power(w) |
No-load Speed(rpm) | Cable length(m) | Borehole Depth(mm) |
Net/Gross Weight(Kgs) |
Packing Size(cm) |
|---|---|---|---|---|---|---|---|---|---|
| OND-940/2 | ~16”(~400) | 110/220~ | 50-60 | 5180 | 320/500 | 3.5 | 520 | 22/25 | 104*38*24 |
| OND-940/2E | ~16”(~400) | 110/220~ | 50-60 | 5180 | 100-320/500 | 3.5 | 520 | 22/25 | 104*38*24 |
| OND-940/3 | ~16”(~400) | 110/220~ | 50-60 | 5180 | 310/460/620 | 3.5 | 520 | 22/25 | 104*38*24 |
| OND-940/3E | ~16”(~400) | 110/220~ | 50-60 | 5180 | 100-310/460/620 | 3.5 | 520 | 22/25 | 104*38*24 |
| OND-945/2 | ~18”(~450) | 110/220~ | 50-60 | 5380 | 250/410 | 3.5 | 520 | 23/26 | 104*38*24 |
| OND-945/2E | ~18”(~450) | 110/220~ | 50-60 | 5380 | 100-250/410 | 3.5 | 520 | 23/26 | 104*38*24 |
| OND-945/3 | ~18”(~450) | 110/220~ | 50-60 | 5380 | 260/390/530 | 3.5 | 520 | 23/26 | 104*38*24 |
| OND-945/3E | ~18”(~450) | 110/220~ | 50-60 | 5380 | 100-260/390/530 | 3.5 | 520 | 23/26 | 104*38*24 |
| OND-950/2 | ~20”(~500) | 110/220~ | 50-60 | 5580 | 250/410 | 3.5 | 520 | 24/27 | 104*38*24 |
| OND-950/2E | ~20”(~500) | 110/220~ | 50-60 | 5580 | 100-250/410 | 3.5 | 520 | 24/27 | 104*38*24 |
| OND-950/3 | ~20”(~500) | 110/220~ | 50-60 | 5580 | 260/390/530 | 3.5 | 520 | 24/27 | 104*38*24 |
| OND-950/3E | ~20”(~500) | 110/220~ | 50-60 | 5580 | 100-260/390/530 | 3.5 | 520 | 24/27 | 104*38*24 |
